Dyno Banyo Bataryası
0,00 TL
Technical Information |
| Product Standard TS EN 817 (Single Control) |
| Manufacturer Warranty 6 Years (Painted And Coated Products For 2 Years) |
| Color / Finish Chrome |
| Aearator Type M24X1 Male Threaded |
| Flow Rate 7.5 - 9 Lt / Min (3 Bar) |
| Operation Type Ceramic Disc Cartridge Ø35 mm With Leg |
| Installation Connection Type From The Wall |
| Body Raw Material Brass |
| Shower Connection G1/2" |
| Wall Connection Axis Dimension 150±1 mm |
| Dimension Of Wall Rosette Ø60 mm |
| Number Of Control Handle Single |
| Material Of Control Handle Metal |
| Shower Diverter Type Automatic 1/2" |
| Wall Connection Thread Type 1/2" |
| Max. Performance Temperature 80°C |
| Suggested Performance Temperature 60°C |
| Max. Performance Pressure 10 Bar |
| Suggested Performance Pressure 3 Bar |
| Min. Performance Pressure 0.5 Bar |
| Suggested Min. Pressure 1 Bar |
| Product Total Height 115 mm |
| Spout- Wall Distance 168 mm |
Resources |
| TS EN 817 Certificate |
